Primex ABS Plastic

Cut-to-Size Calculator

Enter Specifications
Color
Unit
Thickness
inches

Width
Whole-number
Fraction
inches

Length
Whole-number
Fraction
inches
Quantity
sheets
From $15.00
Edge Finish

Machined and rounded edges available starting at sizes 6"x6" (152x154mm) or greater.

For gluing
Photo of routed edges
Edge Shape
Minimum length 6" Minimum length 155 mm
$1.55 per lineal
$5.09 per lineal
NOT AVAILABLE FOR THIS ITEM
Corner Shape
$6.50 / pc | 1-4 corners
inches
Illustration of measuring radius corners
$7.25 / pc | 1-4 corners
inches
Illustration of measuring chamfered corners
Holes
hole
diameter
holes
per sheet

After placing your order you will receive an email with instructions for sending us hole sizes and their locations.

Please note any special instructions in the comments during checkout.


Cut to size orders are currently taking 1 to 2 days (M-F) to process.

Cut to size orders are cut with table and CNC panel saws and have a cut tolerance of +/- .060”. Plastic sheets have a thickness tolerance of +/- 10% and can have thickness variations throughout the sheet. Cut to size items cannot be returned for a refund or exchange.

Sheet sizes, colors, thicknesses and products available on our website are available at TAP Plastics stores.

Visit your local TAP Plastics store where cut-to-size orders often take less than five minutes, start to finish.

Primex Custom-Cut Recycled ABS Sheets

Order ABS plastic sheeting from TAP Plastics for all your DIY home and commercial projects. This strong, lightweight material has hundreds of applications. By getting a cut-to-size ABS plastic sheet, you will have exactly as much as you need, reducing overall costs and waste. The black color offers versatility, and you can prime and paint it to your preference.

What are Black ABS Sheets for?

Black general-purpose recycled ABS plastic (acrylonitrile butadiene styrene) is a high-strength impact-resistant thermoplastic.

ABS thermoforms easily due to its exceptional hot strength, and it can be formed on wood, epoxy, ceramic and aluminum molds. Its forming temperature is 300 to 350 degrees Fahrenheit. For best results, the mold temperature should be 150 to 190 degrees. ABS is textured on one side and has a smooth unfinished surface on the other.

Whether sawed, glued, drilled or bent by heat, we are confident that ABS plastic can help you achieve your desired results. ABS materials hide wear and tear, making them an excellent choice for construction professionals and hobbyists who fully embrace the DIY concept of hands-on participation. As an affordable, long-lasting and versatile material, ABS is already found in many items around your home and office. ABS is recyclable as well, making it an eco-friendly choice.

Some of the many things you can make with black ABS include automotive parts, fittings, 3D building components, electronic enclosures, garden tools, machine prototypes, boat instrument panels and point-of-sale displays. It has good rigidness, impact resistance, dimensional stability and weather resistance, making plastic ABS appropriate for indoor and outdoor use. Watch our video below to see how you can cut plastic sheets with straight lines or curves.

Custom ABS Plastic Sheets

TAP Plastics offers cut-to-size ABS sheeting in any dimensions you need. Half a dozen thicknesses are available, so whether you need a 1/16” plastic sheet, a 1/8” ABS plastic sheet or a 3/8” sheet, we have them available. Select your specifications for thickness, width and length using the Cut-to-Size Calculator. We do measurements in millimeters or inches to match the rest of your project. You can also add routed or rounded edges, radius corners, drilled holes and more for an additional cost. Click the “Available Options” tab to see further customization choices. If you’re trying to decide whether ABS plastic is the right material, a sample ABS plastic sheet is available for a small fee.

Cut-to-size ABS plastic can take one to two business days to process before shipping. You can visit us in-store to receive your custom order, often in five minutes or less. We also have many of the products that are required to work with ABS, including strip heaters, plastic weld and dispensing guns. Not exactly sure of what you need? Please feel free to contact your nearest TAP Plastics store or email info@tapplastics.com today. We look forward to hearing from you! Register for an account to check out faster and track the status of existing orders.

Note: It is the buyer's responsibility to ensure the suitability of this material for use in individual applications. We highly recommend material sampling be done in support of any material selection criteria.



TAP Video: How to cut plastic sheet

Solvent Polishing ABS Plastic


For fractions, decimals and millimeters conversion chart, click here.
